Small Area Installation (Home, factories, shops, Offices, work shops etc)

CCTV at Small area installations is a easy task. Camera recommended are Dome, Bullet PTZ (if required). We recommend IP Camera with NVR but Analog Camera with DVR are more cost effective for this segment. Entry gate specifically focusing on entry area.

• Working areas should be covered with dome camera or fish eye if work shop. Mic’s can be added to record voice.
• Perimeter area should be covered by using Bullet cameras. Now a days basic IP Camera’s comes with features like line crossing, head count etc can be used for getting alarms or email Alert. Now a days self Audio announcement camera’s also available in case of motion is detected
• Motion detection lights can be used to distract people from entering the premises. These Can be programmed in such a way that we will only operate at night.
• By connected internet to recording all camera’s can be viewed on mobile or remote PC.
• Cable to use:- Cat-6 or 3+1 Coaxial cable. Can be viewed remotely using internet.

Mid & Large Area Installation (large Factories, Housing Townships)

We get ample variety of camera types like Fish eye, Multi lens camera, PTZ, Vandal proof camera, Box cameras etc.

• NVR can be used with Raid facility to ensure data security.
• System should be programmed to provide alerts on mails in conditions of exceptions happens.
• LAN repeaters can be used to extend the cable distance upto 300 meters.
• POE switch reduces the power cost as same cable carries power and data.
• No distortion in picture as it is a digital image.
• Strong data compressions available to increase data storage.
• External DAS/NAS can be connected if data size is large and want to be preserved for longer period of time.
• Structured cabling can be done using Cat 6 and OFC with Passive accessories. Can be viewed remotely using internet.

Multi Location installation.

Multi Location installation with centralized monitoring using internet as media can be done. A central Server/OC is used with Monitoring Software to view all the added locations. It is preferred to have same brand of camera’s installed at all locations.

NVR Cascading

In case multiple NVR’s are installed in a premises, we can cascade them at a viewing location using another NVR that means all NVR (Max 20 on one NVR) can be viewed at viewing location using 8 Channel NVR, this avoids use of Computer and makes the system reliable.
